Capability up to 700mm X 400mm
AlphaD21LiB5
AlphaD21LiA5
AlphaD21MiA5
Capability up to 118 in X 31 in X 28 in
Mazak VTC-800/30SR
Mazak VCN 510C
Mazak VCN 430B
Mazak VCN 530C
Mazak VTC 300C
Capability up to 560 mm X 630 mm
Mazak PFH 4800's on a 10 pallet
Mazak Pallatech Cell
Twin Spindle/Twin Turret/Y axis
Bar Fed, Robot and Gantry Load/Unload
13" Max Turning Diameter
36" Max Distance Between Spindles
Axial and Radial Live Tools
Twin Spindle/Twin Turret/Y axis
Axial and Radial Live Tools
12' Bar Feeder
32 mm (1.260") Max Turning Diameter
8.062" Max Distance between Spindles
Zeiss Contura G2 CMM's allow us to hold our production to the highest industry standards while using Zeiss's Calypso software.
Our CMM's are capable of inspecting pieces up to 48" X 96".
The IM-7500 can perform up to 99 measurements in seconds and automatically generate inspection reports while simultaneously tracking measurement trends and variations.
Our 14" diameter screen Micro-Vu Optical Comparator is equipped with:
Micro-Vu Q16 Computational Readout
Q-Axis Display for Electronic Protractor Thru the Lens Surface Reflector
The Renishaw Equator 300 system is accurate between 40 °F and 122 °F and is capable of scanning speeds in excess of 7.5 in/sec.
Renishaw Equators enable process control with highly repeatable gauging technology with 100% inspection of parts.
iRVision enables our robots to be fully-integrated vision detections systems, making the production process faster and more reliable.
